Application
→Used for testing and studying the torque performance of bone screws, fracture torsion angle of bone screws, axial pressure performance of bone screws (metal bone screws, absorbable bone screws, self-tapping bone screws, intramedullary screws, etc.).
→Comply with standards:
→ASTM F543 Standard specification and test methods for metallic medical bone screws
→ASTM F1264 Implants for orthosynthesis-Metallic lockable intramedullary nail
→Max. torque: 20N.m
→Torsion speed: 0-30rpm
→Min. resolution of torsion angle: 0.1 º
→Max. distance between two chucks: 0-300mm
→Relative error of torsion angle: Within ±1% of setting value
→Loading rate: 20N/s
→Central height of main shaft: 130mm
→Dimension of loading machine (L*W*H): Approx. 1000x360x470mm
→Working voltage: 1 phase, 220VAC±10% 50Hz
