Applications
→Used to determine the impact resistance capacity of paper gypsum board, comply with GB/T9775.
→The impact height is manually adjustable and the steel ruler shows the scale.Simple operation, easy to operate, high efficiency.
→Fill the sand box with fineness of 0.5mm and scrape it flat with a darby and then put the test product after treatment on the surface of sand. Let the steel ball fall freely from certain height on the diagonal intersection of the sample. And then check the crack at the back of the sample. The most serious condition of five plates is take as the result of the impact resistance of this group of samples.
Specification
→Max. impact height: 1000mm, adjustable
→Diameter of impact steel ball: 50mm
→Mass of impact steel ball: 510g
→Test sample size (L*W): 300mm*300mm
→Power: 220VAC, 50Hz
