Application:
→ It can be used for static test and dynamic fatigue test for leaf spring for automotive, to determine the spring rate.
→Comply with standard ISO18137 Leaf Springs-Technical Specifications.
→It can apply axial cyclic force to the test within a certain frequency range, including loading system, force measuring system, control system and data acquisition system.
→Max. Static load: ±20kN, accuracy of indication: ±1%（2%-100%）
→Max. dynamic load: ±15kN, dynamic fluctuation: less than ±1%FS
→Amplitude of actuator: ±75mm
→Frequency: 0.1-3Hz
→Control mode: load, displacement, deformation
→Test waveform: sine wave
→Power : 5.5kW
→Max. span between bearing: about 2100mm, with sliding support
→Max. vertical test space: 800mm
