100kN.Concrete tensile Testing Machine(Concrete axial Tension)(CE)
100kN.Electronic Universal Testing Machine
Introduction
→ Used in axial tensile test, axial tensile strength, ultimate tensile strain, tensile elastic modulus for concretes.
→ Concrete axial tensile sample and embedded parts: loop tensile A (100x100x550mm), rod tensile B (M16/Ø150x500mm), clamping tensil C (100x100x600mm), plate tensile D (Ø150x300~500mm)
Technical specifications
WDW-H100 |
||
No. |
Inspection items |
Specifications |
1 |
Max. load |
100kN |
2 |
Load resolution |
1/±300000F.S |
3 |
measuring range of load |
0.4%-100% / 1%-100% |
4 |
Relative error of indicating value |
±0.5% |
5 |
Measuring range of deformation |
0.2-100%F.S |
6 |
Speed range of displacement |
0.001-600mm/min |
7 |
Tensile test space |
1100mm |
8 |
Span |
510mm |
9 |
Working voltage |
220V±10% 50Hz,1ph |
10 |
Motor power |
2.0kW |
11 |
Dimension (L*W*H) |
1050*560*2450mm |
