Introduction
|
TLW-D100N-50kN
Two-position Spring Tension and Compression Testing Machine
|
||||
|
1
|
Load capacity
|
100N-10000N
|
20kN/25kN
|
30kN/50kN
|
|
2
|
load accuracy
|
Class 0.5 / Class 1
|
||
|
3
|
measuring range of load
|
0.4%-100%FS/1%-100%FS
|
||
|
4
|
relative error of indicating value of load
|
Within ±0.5%/±1.0%
|
||
|
5
|
load resolution
|
1/±300000FS
|
||
|
6
|
speed range of load
|
0.005-5%FS/s
|
||
|
7
|
Speed accuracy of load
|
If speed＜0.05%FS, accuracy within ±1% of set value.
If speed ≥0.05%FS, accuracy within ±0.5% of set value.
|
||
|
8
|
displacement resolution
|
0.005mm
|
||
|
9
|
speed range of deformation
|
0.005-5%FS/s
|
||
|
10
|
speed accuracy of deformation
|
If speed＜0.05%FS/s, accuracy within ±1% of set value.
If speed ≥0.05%FS/s, accuracy within ±0.5% of set value.
|
||
|
11
|
speed range of displacement
|
0.001-600mm/min
2m/min&80in/min-25m/min&1000in/min
|
||
|
12
|
speed accuracy of displacement
|
Within ±0.2% of the set value
|
||
|
13
|
Span between columns
|
400mm
|
400mm
|
500mm
|
|
14
|
Crosshead stroke
|
0-1000mm
|
0-1000mm
|
0-1200mm
|
|
15
|
Working voltage
|
220V±10% 50Hz
|
||
|
16
|
Motor power
|
400W
|
750W
|
2000W
|
|
17
|
Dimension of loading frame (L*W*H)
|
860x460x1750mm
|
940x520x1850mm
|
1050x560x2150mm
|
