→MJ - 10;1000g Radiator tank drop-ball Impact Tester
→MJ - 15;1500g Radiator Radiator tank steel ball Impact Tester
Application:
→Drop the steel ball of specified quality from the specified height, and test the energy required for cracking or destruction of the specimen under the impact of falling ball.
→Ceramic products for sanitary ware and kitchenware, plastic bottle caps, plastic sheets, small diameter plastic pipes, glass and hardware products for doors and Windows, wood sheets, film products, auto parts, construction materials and other non-metallic materials are tested and studied for falling ball impact performance.
→To determine the impact resistance of automobile radiator water pipe mouth and water chamber, and to test and evaluate the impact resistance of radiator water tank and production materials.
→Ergonomic design, machine - friendly, machine - friendly, in line with the human - machine - environment system, efficient, healthy, comfortable, safe.
→High rigidity load bearing frame, high quality precision steel ball, free fall impact.
→Quick adjustment of impact height and locking device, vertical ruler, accurate indication, high efficiency impact test.
→Mobile control frame, fast fixture, convenient clamping attachment, safe and convenient.
→Safety cover, three side door, convenient radiator water tank installation.
→Automobile motor vehicle water tank (radiator) is the main parts of the car cooling system, cooling water in the water jacket heat absorption, flow to the radiator after the heat dissipation, and then return to the water jacket circulation, temperature regulation.
→Water-cooled engine heat exchanger, composed of radiator core, water pipe, cooling air blade, upper water tank, lower water tank, etc.
→The upper and lower water chamber of all automobiles and motor vehicles is composed of the upper and lower halves and is formed by pressing.
→Cooling air blades constitute the air flow channel, the car driving, fan suction and wind speed, so that a large number of cold air through the air channel circulation, the heat will be dispersed to the atmosphere, to achieve the cooling effect.
Technical Specification:
→Impact height of steel ball : 200 ~ 1000mm (manual adjustment of any height, ruler indication)
→ 250 g impact ball: 250 g ± 5 g, Ф40 mm ± 0.1 mm
→1040 g impact ball: 1040 g ± 10 g, Ф63.5 mm ± 0.1 mm
→1500 g impaact cylinder: Ф35 x200mm
→Power supply voltage: 220V±10%, 50Hz (reliable grounding is required)
→Machine size (L*W*H) : 900x900x1700mm
→Machine weight: 65kg
Main configuration:
→loading frame with high rigidity, high stability(including impact height adjusting locking device and safety shield)
→250g/1040g/1500g impact steel ball
→1500g impact cylinder 1 set
→control box holder 1 set
→anchor bolts (adjust the level of the machine)1 set
