6000mm/min High Speed High & Low Temperature Tensile Testing Machine

Used in tension test at room temperature, high and low temperature for metals,nonmetals, alloy materials and composites.
High speed tensile test at high and low temperature
High speed compression test at high and low temperature
High speed cyclic tensile and compression test at high and low temperature
HST-D-HLT High speed tensile testing machine at high and low temperature
HST2-D series testing system 2m/min high speed tensile testing machine
HST2-D-HLT series testing system 2m/min high speed tensile testing machine at high and low temperature
HST6-D-HLT series testing system 6m/min high speed tensile testing machine
HST6-D-HLT series testing system 6m/min high speed tensile testing machine at high and low temperature
High speed tensile test
elevated temperature tensile test
low temperature tensile test
high speed high & low temperature tensile test
max. test force: 100N/200N/500N/1000N/2000N/5kN/10kN/20kN/50kN/100kN
test speed: 0.0001-6000mm/min (240in/min) (100mm/s)
high speed tensile starting time: 0-6000mm/min/1.0s
high speed tensile stop time: 6000mm/mim-0/2.0s
high speed accuracy: ：±0.2%
speed resolution: 0.033μm
control accuracy of position: ：±0.2%
sampling frequency: 1000Hz (10Hz-1000Hz)
load accuracy: ：±0.5% of displayed value
GB/T4338 Metallic materials-Tensile testing at elevated temperature
ASTM E21-05.Standard Test Methods for Elevated Temperature Tension Test of Metallic Materials
ASTM E 8M-08.Standard Test Methods for Tension Testing of Metallic Materials [Metric]
BS EN10002-5：2001
BS EN10002-1：2001
ASTM E9-89a(2000).Standard Test Methods of Compression Testing of Metallic Materials at Room Temperature
EN 14024：2004(E)
GJB150.4A-2009 Laboratory environmental test methods for military material-Part4：Low temperature test
GB/T11158-2008 Specifications for high temperature test chambers
GB/T10592-2008 Specification for high/low temperature test chambers
GB/T228.1-2010 Metallic materials-Tensile testing-Part1：Method of test at room temperature；(ISO 6892-1：2009.MOD)
GB/T228.2-2015 Metallic materials-Tensile testing-Part2：Method of test at elevated temperature；(ISO 6892-2：2011.MOD)
GB/T 25827-2010 General specification of superalloy plates and strips
GB/T10067.4 Basic specifications for Electroheat installations-Part4：Indirect resistance furnaces
GB5237.6-2012 Wrought aluminium alloy extruded profiles for architecture- Part6：Thermal barrier profiles
GB/T10623 Metallic materials-Mechanical testing-Vocabulary(ISO 23718：2007.MOD)
precise gapless ball screw, free of vibration, high stiffness, stable dual column loading frame.
with high precise loadcell, wide linearity, good stability to ensure the accuracy of load.
high speed, low vibration, free of maintenance, quiet AC servo motor drive system.
with photoelectrical isolation design, with features of anti-interference.
、
