Application
→Used for orthopedic bone plate bending fatigue performance test, fixed bone plate bending fatigue test, stainless steel bone plate fatigue test, bone biological material fatigue test, medical device products and related products fatigue test, fatigue life of medical components and high cycle fatigue test.
→Comply with standards:
→ASTM F1264 Implants for orthosynthesis-Metallic lockable intramedullary nail
→ASTM F382 Standard specification and test method for metallic bone plates
→Max. static load: ±5kN
→Max. dynamic load:±5kN
→Max. Amplitude: ±30mm
→Frequency: 0.1-15Hz
→Test space: 500mm
