→Used in tensile test to determine breaking force for ordinary wire rope, flexible wire rope, ordinary strength grade wire rope, high strength grade wire rope, extra high strength grade wire rope and other general purpose wire rope.
→Mainly used for static load test of mechanical tensile strength of rope, chain, steel strand, power line, etc.
→It is also can be used in proof load and breaking load test for anchor chains, chains accessories, shackle, slings, marine anchor, high strength steel wire rope, fishing industry chains, high strength round-link chain and other flexible components, etc.
→It is widely used in construction engineering, quality inspection, shipbuilding, petrochemical, aerospace, machinery manufacturing, wire and cable and other industries.
Comply with various standards:
→ISO3108 Steel wire ropes for general purposes-Determination of actual breaking load
→ISO2408 Steel wire ropes for general purposes
→GB/T34198-2017 Steel wire for cranes
→ISO4344 Steel wire ropes for lifts
→GB/T20067 Large diameter steel wire ropes
→ISO17746 Steel wire rope net panels for engineering
Specifications:
→Max. Load:3000kN
→Max. distance between jaws: 4500mm or customizable
→Space adjustable interval (by bolts): 500mm
→Piston stroke: 0-1500mm, customizable
→Adjustable speed of jaws movement: 500mm/min
→Displacement resolution: 0.01mm
→Span between columns: 800mm, customizable
→Dimension of loading frame (L*W*D):9500x1650x1000mm, customizable
→Dimension of control cabinet (L*W*D):1200x900x1100mm, customizable
