→ Used in compression and flexure tests for common cement, special cement, characteristic cement, concrete mortar,tiles, rocks and so on.
→ It can be used for both compression and flexure test at a time.
→ ISO 679, ISO 10426-1, ISO 10426-2, ISO 10426-3, API RP 13J, API Spec 10A, ASTM C109, ASTM C188, ASTM C452.
→ max. compression load: 300kN
→ max. flexural load: 10kN
→ compression loading rate: 0.2kN/s-10kN/s
→ flexure loading rate: 10N/s-500N/s
→ work voltage: 220V±10% 50Hz
→ distance between two platens: 200mm
→ span between columns: 300mm
→ Dimension of loading frame(L*W*H): 1200x500x1300mm
